Phase matched sma cables. Our sma cables connector 2 series standard options include. How to phase match cables after i read the precedent posts on this topic i would add my personal opinion. Sma to sma assemblies are assembled from 45 different coaxial cable types and 72 unique sma connectors. Our sma to sma cable assembly products are available with options that include heatshrink booting customer defined labeling and more.

Delivered such phase matched rf cables to drdo in various projects. Sma cables are available from fairview microwave in standard or custom lengths with a variety of the most popular connector and coax options. This matched cable pair consists of two cables sma m to sma m which are matched in propagation delay within 25 ps. The cables of a phase matched set need to be thermally stress relieved before phase matching.

Options for straight right angle bulkhead and quick connect connections. I think there is an another way. 1 85mm 10 32 2 92mm 7 16 din bnc mcx mini smp mmcx n qma sma smb smc smp ssma ssmb ssmc and tnc in right angle straight designs and with female jack male or plug genders. Typically cables with a solid dielectric will have a low v p and cables with a foamed or taped dielectric material which allows for the introduction of more air will have a higher v p.

Rf microwave interconnect and precision test cables for 50 ohm and 75 ohm systems from dc to 50 ghz with a wide selection of connectors including 2 4mm 2 92mm sma n type f type and bnc. We supply phase matched cable sets semi rigid and flexible rf cables upto 18 ghz. If your semirigid is 141 and if your connector is the sma that use the no central pin a type of sma that use the central cable to do the male pin. All combinations of male and female connectors.

In delivering phase matched assemblies the selected cable type or construction must be carefully screened to ensure a consistent v p between cable batches. 1 connect one end of the calbles to the connectors. Length adjustment to match 10 cables with vp ranging from 81 0 to 83 0. At spectrum elektrotechnik gmbh the cable is preconditioned by exposing it several times to temperatures of 54 c to 125 c in some cases even between 71 c to 200 c.
